LCD Pure Display El Light-emitting Electronic Watch Movement

We provide LCD Pure Display El Light-emitting Electronic Watch Movement, which has anti-static, low power consumption, low current, crisp sound, high bright backlight, wide viewing angle, clear font and long life. We are dedicated to LCD electronic watch movement manufacturing for many years, and most of our products cover Hong Kong, Japan, USA, Europe, South America, Southeast Asia, etc. We are looking forward to be your long-term partner in China.

Send Inquiry

Product Description

As the professional manufacturer, we would like to provide you LCD Pure Display El Light-emitting Electronic Watch Movement. We have nearly ten years of production and sales experience, with mature technical resources and production technology, looking forward to becoming a long-term partner with you.

LCD electronic watch movement parameters (specifications)

Size: θ38.0
Function: LCD display
Shape: Round
Product Description: Function Introduction 10-digit chronograph function, displaying hours, minutes, seconds, day, month and week. Alarm and full time chime 12/24 hour system selection 1/100th of a second stopwatch

LCD electronic watch movement product quality standards

Dimensions: θ38.0mm
Thickness (with buzzer): 9.0mm
Operating temperature: -10℃~+60℃
Operating voltage: 3.0V
Accuracy: ±60 sec/month
Battery type and capacity: CR2032 (capacity 240m Ah)
Static average current: ≤ 2.0 u A (static maximum current: 3.0 u A)
Average alarm current : ≤ 1.64m A (maximum alarm current: 6.5m A)
EL luminous average current: ≤ 8.62m A (EL luminous maximum current: 10m A)
Battery Service life (85%): ≥ 24 months (Japanese power)
(lights on 4 times per press, 3 seconds each time, 12 seconds total; alarm goes off for 60 seconds per day)

FAQ

Q1: Are you a factory?
A1: Yes
Q2: How long do your movements last?
A2: More than two years
Q3: Can you do custom movements?
A3: Yes, OEM/ODM is available
Q4: How many varieties and sizes of movements are available?
A4: Over a hundred different kinds
Q5: Is there a choice of lighting colors?
A5: May
Q6: Is the movement warranted?
A6: FreeWarranty
